What is Precision Wire Forming？

Precision wire forming is a CNC-controlled manufacturing process that shapes metal wires into complex geometries with ±0.02mm accuracy, widely used in medical devices, electronic connectors and automotive components.Stainless Steel Compression Springs

Key Advantages

Micron Precision

Linear motor drives achieve ±5μm repeatability.

Complex Forming

Creates 3D shapes with multiple angles/radii in one operation.

Material Efficiency

Reduces waste by 95% vs machining.

Quick Changeover

Tooling/program change in 3 minutes.

Surface Protection

Non-cutting process preserves material properties.

How They Work

Servo feeding system advances wire precisely while multi-axis CNC tools perform bending/coiling at programmed positions.

Key Characteristics

✔️

Material Range - Processes 0.05-10mm wires including specialty alloys

✔️

Angle Accuracy - ±0.1° bending tolerance

✔️

Minimum Radius - 0.5x wire diameter bending capability

Key Design Factors

✔️

Springback Compensation – AI predicts 0.1-3° compensation based on material

✔️

Speed Optimization – Auto-adjusts 10-100 cycles/min based on wire size

✔️

Tool Life – Carbide tools guarantee 500k+ cycles lifespan

Manufacturing Process

Material Prep

Laser measurement ensures ±0.002mm diameter.

Straightening

12-roller system achieves 0.01mm/m straightness.

CNC Feeding

Linear motor drive with ±0.005mm accuracy.

Multi-Station Forming

4-8 stations process complex features simultaneously.

In-Process Inspection

Laser scanning monitors critical dimensions.

Heat Treatment

300-800℃ in controlled atmosphere.

Surface Treatment

Options include micro-arc oxidation/nano-coating.

Final Inspection

3D optical scan + VCI vacuum packaging.
