What is Coil Forming？

Coil forming is a manufacturing process that transforms metal wire into helical structures through precision winding, primarily used to produce springs, inductors and medical components with 0.1-50mm diameter precision.Stainless Steel Compression Springs

Key Advantages

High Precision

CNC control achieves ±0.01mm coil spacing accuracy.

Complex Structures

Produces tapered, variable-pitch and multi-layer coils.

Material Versatility

Compatible with specialty wires like shape-memory alloys.

High Efficiency

50-200 coils per minute production speed.

Surface Integrity

Non-cutting process preserves wire properties.

How They Work

Wire feeds through guides onto mandrel, with CNC-controlled rollers forming helical structures according to programmed parameters.

Key Characteristics

✔️

Diameter Range - Standard 0.1-20mm, up to 50mm with special equipment

✔️

Pitch Control - Minimum pitch 0.8x wire diameter

✔️

Concentricity - ≤0.02mm radial runout on premium machines

Key Design Factors

✔️

Springback Compensation – 0.5-3% overwind based on material modulus

✔️

Winding Tension – Maintain 5-15% of wire's tensile strength

✔️

Mandrel Design – 0.1-1° taper for release, HRC60+ surface hardness

Manufacturing Process

Wire Prep

Select straightened wire of required diameter/material.

Straightening

Multi-roller system achieves ≤0.1mm/m straightness.

Feeding

Servo-controlled with ±0.005mm accuracy.

Primary Winding

CNC rollers create basic helix.

Pitch Forming

Spacing wheels regulate coil separation.

End Forming

Laser cutting/mechanical clamping finishes ends.

Annealing

300-500℃ stress relief in controlled atmosphere.

Inspection

100% automated optical dimension check.
